TECHNICAL DATA
Model EON 700W
Article no. ZPU-700S
EAN code 0753263078445
Weight (without/with package) 1.40kg / 1.68kg
AC Input 200-240V / 5.5A
Frequency 50Hz
+5V 20A
+3.3V 20A
+5V & +3.3V combined 100W
+12V1 53A
+12V2 --
+12V1, +12V2 combined 636W
P.F. >0.9
-12V 0.4A / 4.8W
+5VSB 2.5A / 12.5W
Maximum Power 700W
Connectors
20+4 PIN ATX 1
8 PIN EPS (4+4) 2
8 PIN PCIe (6+2) 4
SATA 4
MOLEX/FLOPPY 2
Cable length (mm)
20+4 PIN ATX 650
8 PIN EPS (4+4) 700/100
8 PIN PCIe (6+2) 2 x 550/150
SATA 450/150/150
MOLEX/FLOPPY 450/150/150
Features
ATX12V Version ATX 12V 2.3
Efficiency 80 PLUS® 230V EU
Dimension (DxWxH) 140mm x 150mm x 86mm
PFC Active PFC (0.9) (only 230V)
Fan 120mm silent fan
Security AFC (Automatic Fan Speed Control)
OPP (Over Power Protection)
OVP (Over Voltage Protection)
SCP (Short Circuit Protection)
SIP (Surge & Inrush Protection)
UVP (Under Voltage Protection)
Warranty 24 Months
