Shell
ABS
Net Weight
0.059 kg (0.13 lb)
Dimensions (W × H × D)
87.00 mm × 25.00 mm × 51.00 mm (3.43'' × 0.98'' × 2.01'')
Operating Temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage Temperature
–40 °C to 85 °C (–40 °F to 185 °F)
Operating Humidity
5% to 95% (no condensation)
Relative Humidity
5% to 95% (no condensation)
Power Supply
5 VDC, 0.6 A
Installation Mode
Desk-Mounted
Max. Power Consumption
3 W
Surge Protection
2 KV
Network Parameters
Porti
5 × Gigabit RJ45 port
MAC Address Table
2 K
Switching Capacity
10 Gbps
Packet Forwarding Rate
7.44 Mpps
Internal Cache
1 Mbits
Approval
EMC
CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue 7:2020),RCM (AS/NZS CISPR 32: 2015)
Safety
CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017)
Chemistry
CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No.1907/2006)
