Chipset Intel Z890
CPU SUPPORT Support for Intel Core™ Ultra 9 / 7 / 5 processors in the LGA1851 package
* Please refer to www.biostar.com.tw for CPU support list.
MEMORY Supports Dual Channel DDR5 - 8000+(OC)/ 7800(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600
4 x DDR5 DIMM Memory Slot, Max. Supports up to 192 GB Memory
Each DIMM supports non-ECC 8/ 16/ 24/ 32/ 48 GB DDR5 module
Support Intel® Extreme Memory Profile (XMP) memory modules
* Please refer to www.biostar.com.tw for Memory support list.
INTEGRATED VIDEO By CPU model
Supports DX12
Supports HDCP
STORAGE Total supports 4 x M.2 socket and 4 x SATA III (6Gb/s) ports
Intel Core Ultra Processors
1 x M.2 (M Key) Socket (M2M_CPU_1):
Supports M.2 Type 2280 SSD module
Supports PCIe 5.0 x4 (128Gb/s) - NVMe SSD
1 x M.2 (M Key) Socket (M2M_CPU_2):
Supports M.2 Type 2280 SSD module
Supports PCIe 4.0 x4 (64Gb/s) - NVMe SSD
Intel Z890 Chipset
1 x M.2 (M Key) Socket (M2M_SB_1):
Supports M.2 Type 2280 SSD module
Supports PCIe 4.0 x4 (64Gb/s) - NVMe SSD
1 x M.2 (M Key) Socket (M2M_SB_2):
Supports M.2 Type 2280 SSD module
Supports PCIe 4.0 x4 (64Gb/s) - NVMe SSD
4 x SATA III Connector (6Gb/s):
Supports AHCI, RAID 0, 1, 5, 10 & Intel® Rapid Storage Technology
* Specifications vary by CPU types
LAN Realtek RTL8125D
10/ 100/ 1000/ 2500 Mb/s auto negotiation, Half / Full duplex capability
AUDIO CODEC Realtek ALC1220
7.1 Channels, High Definition Audio
USB 2 x USB 3.2 (Gen2) Type-C ports
(1 on rear I/O and 1 via internal header)
9 x USB 3.2 (Gen2) ports
(7 on rear I/O and 2 via internal header)
4 x USB 2.0 ports
(4 via internal header)
EXPANSION SLOT Intel Core Ultra Processors
1 x PCIe 5.0 x16 Slot (x16 mode)
Intel Z890 Chipset
1 x PCIe 4.0 x16 Slot (x4 mode)
2 x PCIe 3.0 x1 Slot (x1 mode)
* Specifications vary by CPU types
REAR I/O 2 x WIFI Antenna Ports
1 x HDMI Port (HDMI2.1)
1 x HDMI Port (HDMI1.4b)
1 x DP Port (DP1.2)
1 x USB 3.2 (Gen2) Type-C Port
7 x USB 3.2 (Gen2) Ports
1 x 2.5 Gigabit LAN port
3 x Audio Jack
1 x SMART BIOS UPDATE Button
1 x SMART BIOS USB Port
INTERNAL I/O 4 x SATA III Connector (6Gb/s)
1 x M.2 (E Key) Socket : Supports 2230 type Wi-Fi & Bluetooth module and Intel® GEN2 CNVi
1 x USB 3.2 (Gen2) Type-C Header
(each header supports 1 USB 3.2 (Gen2) Type-C ports)
1 x USB 3.2 (Gen2) Header
(each header supports 2 USB 3.2 (Gen2) ports)
2 x USB 2.0 Header
(each header supports 2 USB 2.0 ports)
2 x 8-Pin Power Connector
1 x 24-Pin Power Connector
1 x CPU Fan Connector
1 x CPU water cooling connector (CPU_OPT)
4 x System Fan Connector
1 x Front Panel Header
1 x Front Audio Header
1 x Internal Stereo Speaker Header
1 x Clear CMOS Header
1 x COM Port Header
1 x TPM Header
1 x Thunderbolt Header
4 x LED Header (5V)
1 x LED Header (12V)
* M.2 (E Key) Wi-Fi card is not provided
RAID Supports RAID 0, 1, 5, 10 for SATA storage devices
Supports RAID 0, 1, 5, 10 for M.2 NVMe storage devices
DIMENSION ATX Form Factor Dimension: 24.4cm x 30.5cm ( W x L )
OS SUPPORT Supports Windows 10(64bit) / Windows 11(64bit)
※Biostar reserves the right to add or remove support for any OS with or without notice.
ACCESSORIES 2 x SATA Cable
1 x I/O Shield
1 x Cable for WiFi Antenna
